DC-9300 Supermarket 2.4G Bluetooth Wireless Barcode Reader Code Scanner CMOS Auto Sleep Hand-free Omnidirectional Barcode Scanner

2.4G Bluetooth Wireless Barcode Reader Code Scanner

Affiliated Classification:

Peripheral

Barcode Scanner

Keywords:

DC-9300 Supermarket 2.4G Bluetooth Wireless Barcode Reader Code Scanner CMOS Auto Sleep Hand-free Omnidirectional Barcode Scanner

Product Enquiry

Product Description

DC-9300 Supermarket 2.4G Bluetooth Wireless Barcode Reader Code Scanner

◎ 4mil scan precision

◎ 24-months warranty

◎ Micro USB cable charging

◎ No need driver, plug and play

◎ Firmware support upgrade on-line

◎ 2.4G&Bluetooth mode, easy operate

◎ Large storege of 40,000 EAN 13 code

◎ Large capacity battery, working for 16 hours

PERFORMANCE PARAMETER
Light Source	White LED (Lighting)
CPU	MIPS @1GHz
Image Sensor	CMOS
Pixels	640x480 pixels
Precision	4 mil
Depth of Scan Field	20-220mm (13mil PCS90%)
Sensitivity	Roll: 360° Skew:±65° Pitch:±60°
Wireless Performance	2.4G: 100M distance (open space); Bluetooth (4.0 HID): 10M distance（open space）
Scan Speed	30fps/s
Memory capacity	Up to 520,000 characters (40,000 EAN 13 barcodes)
Scan Mode	Manual & Continuous
Decoding Capability	1D: UPC-A; UPC-E; EAN-8; EAN-13; Code39; Codabar; Code128; Interleaved 2 of 5; Industrial 2 of 5; Matrix 2 of 5; Code 93; UCC/EAN 128; Code 11; MSI; UK/Plessey ; ISBN/ISSN; GS1 Databar Expanded; GS1 Databar; GS1 Databar Limited.
PERFORMANCE PARAMETER
Dimension	Scanner: L × W × H:170mm × 73mm × 102mm Receiver: L × W × H:19mm × 14mm × 6mm
Weight	200g
Material	ABS+PC
Battery	Rechargeable lithium battery, 2200 mAh, 16 hours (continuous working )
Current(working)	350MA（Working current), 106MA（Static current), <1uA（Standby current）
Temperature	-20℃- 55℃（working temperature)， - 40℃- 80℃（Storage temperature)
Support Interface	USB、USB-VCP(2.4G& Bluetooth)
Charging Mode	Micro USB charging , DC5V (charging voltage), 4.5 hours (charging time)
Communication mode	2.4G, bluetooth, micro USB cable
Indicator	Double LED indicator, buzzer
Humidity	5% to 95%
Illumination	0-100000 lux

Product Description:

POS Scanner is a barcode scanner used in the retail industry. It is usually used in conjunction with the POS system to quickly and accurately scan product barcodes to achieve product information entry, sales statistics and other functions. POS Scanner is an indispensable tool in modern retail operations, improving checkout efficiency, reducing labor costs, and ensuring the accuracy of sales data.

Features:

Fast and efficient: POS Scanner has a high-speed scanning function, which can quickly and accurately read product barcodes, improve checkout efficiency, and save time and costs.

Versatility: In addition to scanning product barcodes, POS Scanner can also support manual input of product codes, price modification and other functions, improving the flexibility of system operations.

Durable and stable: POS Scanner is made of high-quality materials, which is durable and stable, suitable for long-term use in retail environments.

High Sensitivity: The POS Scanner scan head has high sensitivity and is able to accurately read various types of barcodes, including damaged or faded barcodes.

Strong compatibility: POS Scanner is compatible with most POS systems and is easy to integrate into existing systems without additional configuration and complicated installation steps.

Stable data transmission: POS Scanner is connected to the POS system through a stable data transmission method to ensure the stability and accuracy of data transmission.
